TQ1-1515 Small 6" x 6" Label Pneumatic Heat Press Machine
TQ1-1515 Small 6" x 6" Label Pneumatic Heat Press Machine
Printomize America ( LA)
20505 Earl Street
Torrance CA 90503
United States
Choose options
TQ1-1515 Pneumatic Dual-Station Heat Press – 6" x 6"
Product Highlights
- Designed for inner-neck labels, left-chest logos, and other small-format transfers
- Dual-station system for faster production and continuous workflow
- Heavy-duty industrial-grade pneumatic construction
- Includes 6" x 6" and 3" x 3" interchangeable platens
- Thick cast-aluminum heat plate for consistent, even heat
- Self-pressure balancing system for uniform transfers
- Teflon-coated heating plate helps prevent sticking or scorching
- Easy-to-read LCD controller displays time and temperature simultaneously
- Certified 5CE & ROHS compliant
- Powered by an external air compressor (10-gallon minimum, not included)
Key Features
- Max pressure: 0.8 MPa (120 PSI)
- Max temperature: 500°F
- Time range: 0–999 seconds
- Built for high-volume, repetitive label and logo applications
- Compact footprint, ideal for shop tables or production stations
Included in the Box
- 6" x 6" platen
- 3" x 3" platen
- 8mm air line hose
- 8mm to 1/4" compressor connection kit
Specifications
Electrical
- Voltage: 110V
- Current: 10A
- Power: 600W
Machine Dimensions
- Dimensions: 16" x 11" x 24"
- Weight: 33 lbs
Packaging
- Box size: 18" x 13" x 23" / 42 lbs
Ideal For
- Apparel relabeling
- Branding programs
- Uniform programs
- On-demand short runs
- High-volume production environments
