TZ-4050 4 Station High Speed Carousel Heat Press

4-Station High-Speed Carousel Heat Press — MEM TZ-4050

Boost your production efficiency with the MEM TZ-4050 4-Station Carousel Heat Press, engineered for high-volume, professional heat transfer applications. Built with an industrial-grade framework and premium electrical components, this machine delivers consistent results, speed and durability for demanding workflows.

How a carousel changes your workflow

With four stations, an operator loads and unloads garments while the press cycles on another station. There is no waiting for a press to finish before preparing the next garment — the machine is always working.

Key features

• 4-station carousel design — load and unload while pressing
• Up to 150 shirts per hour — sustained output with a single operator
• Industrial-grade construction — heavy-duty steel frame built for continuous use
• Even heat distribution — thick cast aluminium platen for consistent temperature
• Pneumatic pressure system — adjustable 0.6–0.7 MPa, up to 120 PSI
• Digital temperature and time control — precise, repeatable settings
• Adjustable press and lift speed — tuned via solenoid and restriction valves
• Self-pressure balancing — even pressure across the platen
• Teflon-coated heat plate — prevents sticking and protects garments
• Certified — CE and ROHS approved

Applications

DTF (Direct to Film) transfers, heat transfer vinyl (HTV), sublimation printing, screen print transfers, inkjet transfers, and flock and flex applications.

Specifications

• Model: TZ-4050
• Platen size: 16" x 20" (4 stations)
• Electrical: 220V / 2700W
• Max temperature: 500°F
• Time range: 0–999 seconds
• Pressure range: 0.6–0.7 MPa (up to 120 PSI)
• Machine dimensions: 60" x 60" x 55"
• Machine weight: 800 lbs
• Crate size: 57" x 40" x 70"
• Shipping weight: 1,140 lbs

Requirements

• 220V supply
• External air compressor, 20 gallon, not included
• 8 ft x 8 ft of floor space to operate, including room for the operator to work around the carousel

Stepping up to six stations

Our 6-Station Carousel adds two more stations and needs more floor space and more than double the power, so check both before deciding.
